Filter QS4363A0000A YAMASHIN-FILTER Cheap Browse

【Features】
A filter that can be installed in a hydraulic circuit with a filtration accuracy of 10μm, making it ideal for maintaining the cleanliness of the hydraulic oil in the circuit.
The use of aluminum makes it lightweight, compact, and space-saving.
The piping connection port has a highly versatile RC1/2 screw specification.

【Use】
As a filter for general hydraulic oil.
For removing dust from circulation circuits of machine tools, industrial machinery, and transportation hydraulic equipment.

【Specification】
Bore diameter: Rc1/2
Overall length (mm): 142
Overall width (mm): 92.2
Standard flow rate (L/min): 20
Maximum working pressure (MPa): 7.0
Valve set pressure (MPa): 0.10

【Specification2】
Recommended flow rate: 22L/min or less
Filtration accuracy: 10μm
Pipe connection size: Rc1/2 thread
With relief valve
Element replacement type

【Material/Finish】
Aluminum

【Set contents/accessories】
－

【caution】
The element is replaceable.
Loosen the hexagonal part of the case with a spanner, remove the case, and replace the internal element.
